Capabilities
72″ Strilitch Cut-To-Length Multi-Blanking (Slear) Line
Materials:
Hot Rolled P&O, Cold Rolled, Zinc Coated Products, Stainless Steel and Aluminium
Gauge Range:
- DQAK: .021″ to .070″
- 50KSI: .030″ to .065″
- 80KSI:
- Aluminium: .030″ to .125″
Entry Coils:
- Weight: 60,000 lbs Max
- I.D: 20″ Min to 24″ Max
- O.D. 72″ Max
- Width: 16” Min to 72” Max
Exit Sheets:
- Sheet Width: 6″ Min to 72″ Max
- Sheet Length: 12″ Min to 144″ Max
- Pack Height: 24″ Max (including dunnage)
- Pack Weight: 20,000 lbs Max
Width and length tolerance standard to ASTM specifications.
72” Herr-Voss Cut-To-Length Line
Materials:
Hot Rolled P&O, Cold Rolled, Zinc Coated Products, Stainless Steel and Aluminium
Gauge Range:
- DQAK: .028″ to .105″
- 50KSI: .040″ to .090″
- 80KSI: .055″ to .080″
- Aluminium: .040″ to .205″
Entry Coils:
- Weight: 45,000 lbs Max
- I.D: 20″ Min to 24″ Max
- O.D. 74″ Max
- Width: 16” Min to 72” Max
Exit Sheets:
- Sheet Width: CTL/ET Only
- Sheet Length: 16″ Min to 144″ Max
- Pack Height: 20″ Max (including dunnage)
- Pack Weight: 20,000 lbs Max
Width and length tolerance standard to ASTM specifications.
33″ Braner Cut-To-Length Line (Heavy Gauge)
Materials:
Hot Rolled P&O, Cold Rolled, Zinc Coated Products, Stainless Steel and Aluminium
Entry Coils:
- Weight: 18,000 lbs Max
- Gauge: .060″ Min to .312″ Max
- I.D: 20″ Min to 24″ Max
- O.D. 72″ Max
- Width: 5” Min to 33” Max
Exit Sheets:
- Sheet Width: 5″ Min to 33″ Max
- Sheet Length: 9″ Min to 144″ Max
- Pack Weight: 8,000 lbs Max
- Edge Trim: No
Width and length tolerance standard to ASTM specifications
Steel Dimensions is an ISO-9002 certified company in which customer service is our primary goal.
We strive to work with our customers to provide a product that meets or exceeds their specifications.
